BEST SELLERS
Part number Wattage Output Voltage Input Voltage Class 2 Terminal Block Secondary Breaker Num. of circuits
MLE60-24DC-P 6024VDC 120Hz120V 50/60Hz✔single
MLE60-12DC-P 6012VDC 120Hz120V 50/60Hz✔single
ML60S12DC 6012VDC120V 60Hz✔✔single
ML60S24DC b 		6024VDC120V 60Hz✔✔single
ML60S12DC b 6012VDC120V 60Hz✔✔single
ML60S24DC 6024VDC120V 60Hz✔✔single
⇓ click here for more products ⇓
MLE-P - MICRO-LED ELECTRONIC Plastic Housing EMCOD MLE-P Series is Extremely Compact Low profile Constant Voltage, Triac (Phase) Dimmable Electronic LED Driver for Forward and Reverse Phase Dimmers. 5% minimum load. Over load, Short circuit protection. Excellent Line and Load regulation. Wide variety of compatible dimmers, flicker free dimming. Fit in 4" Junction Box. US and Canada UL Recognized, Class 2, UL8750 and UL1310 certified.
Wattage: 60W
Output Voltage: 12VDC and 24VDC 120Hz
Input Voltage: 120V 50/60Hz
All: Class 2, For Dry and Damp Location
Part number Wattage Output Voltage Input Voltage Class 2 Terminal Block Secondary Breaker Num. of circuits
MLE60-12DC-P 6012VDC 120Hz120V 50/60Hz✔single
MLE60-24DC-P 6024VDC 120Hz120V 50/60Hz✔single
⇓ click here for more products ⇓
MLE-UD T24 - MAIN-LED ELECTRONIC UNIVERSAL DRIVER EMCOD MLE-UD T24 Series is Universal Constant Voltage, PWM output, Triac (Phase), 0/1-10V, Resistor, PWM Control, 5 in 1 Dimmable Electronic LED Driver. 5% minimum load. Overload, Short circuit and Thermal protection. Excellent Line and Load regulation. Wide variety of compatible dimmers, flicker free dimming. Dry , Damp and Wet Location. T24 J8 compliant. Working Temperature -40C ~ +60C
Wattage: 30W, 60W, 80W, 96W, 100W, 120W, 150W, 200W, 300W
Output Voltage: 12VDC and 24VDC Output PWM frequency 20kHz
Input Voltage: Universal 100-277VAC 50/60Hz
All:

UL8750 Listed for US and Canada. Class 2 for 12V up to 60W and for 24V up to 96W

Part number Wattage Output Voltage Input Voltage Class 2 Terminal Block Secondary Breaker Num. of circuits
MLE60-12DC-UD T24 6012VDC 20kHz PWM, T24 JA-8100-277V 50/60Hz✔single
MLE60-24DC-UD T24 6024VDC 20kHz PWM, T24 JA-8100-277V 50/60Hz✔single
⇓ click here for more products ⇓
ECV-UD - EMCOD Ultimate Universal Driver Global universal input voltage: 100V-277V 50/60HZ. Universal Output: PWM 4kHz or Linear Amplitude Regulation, setting by integrated in wire compartment switch and adjusting output voltage knob. Universal Dimming: Triac - forward and revers phase, 0/1-10V, PWM and Resistor - 5 in 1dimming options. High PF >95 and low THD <20%. Short circuit, overload and temperature protection. Black powder coated metal case suitable for dry, damp and wet locations. Removable cover on single hinge.
Wattage: 30W, 60W, 80W ,96W ,100W, 120W, 150W, 150W, 200W and 300W
Output Voltage: 12V, 24V, 36V, 48V
Input Voltage: 100V-277V
All: usULc listed, Class P, Type HL. FCC, NEMA 4X, CE, R0Hs. Load range 0.1-100% . Title 24 JA8 compliant.
Part number Wattage Output Voltage Input Voltage Class 2 Terminal Block Secondary Breaker Num. of circuits
ECV60-12DC-UD 		6012VDC 4kHz PWM or Linear100-277V 50/60Hz✔single
ECV60-24DC-UD 		6024VDC 4kHz PWM or Linear100-277V 50/60Hz✔single
⇓ click here for more products ⇓
EDR - EMCOD Din Rail Universal Driver EDR ELECTRONIC UNIVERSAL DRIVER Series is Universal Constant Voltage, PWM output, Triac (Phase), 0/1-10V, Resistor, PWM Control, 5 in 1 Dimmable Electronic LED Driver. 5% minimum load. Overload, Short circuit, and Thermal protection. Operating temperature -40C ~ +60C. Excellent Line and Load regulation. Wide variety of compatible dimmers, flicker free dimming. Dry and Damp Location. Plastic case for Din Rail installation.
Wattage: 60W, 96W and 100W
Output Voltage: 12V, 24V and 48V PWM 4kHz frequency
Input Voltage: 100V-277V range
All: UL8750 Listed for US and Canada. Class 2 for 12V 60W and for 24V  96W, class P
Part number Wattage Output Voltage Input Voltage Class 2 Terminal Block Secondary Breaker Num. of circuits
EDR60-12DC 		6012VDC 4kHz PWM100-277V 50/60Hz✔✔single
EDR60-24DC 		6024VDC 4kHz PWM100-277V 50/60Hz✔✔single
⇓ click here for more products ⇓
ECC-UD - EMCOD Constant Current, Universal Dimming, Multi- Current with DIP Adjustment Triac ( phase cut) forward and revers phase, 0-10/1-10V, Potentiometer, PWM - 5 in 1 Universal Dimming. Universal input voltage 100-277V 50/60Hz. Strong combability, flicker free dimming. Good efficiency >83%. Power Factor 0.99 Cooling by free air convection. Full protection plastic housing IP20 rating for indoor installation. Input, output and dimming terminal blocks for easy installation. Protection: short circuit, over load and over temperature, recover automatically after fault condition is removed.
Wattage: 10W, 20W, 40W and 60W
Output Voltage: 3-65V depend a model and of a current
Input Voltage: 100-277V
Part number Wattage Output Voltage Input Voltage Class 2 Terminal Block Secondary Breaker Num. of circuits
ECC-060-UD 		603-65VDC100-277V 50/60Hz✔single
ES-UD - EMCOD Slim Series Universal Constant Voltage Driver EMCOD ES-UD Series is Universal Constant Voltage, PWM output, Triac (Phase), 0/1-10V, Resistor, PWM Control, 5 in 1 Dimmable Electronic LED Driver. 5% minimum load. Overload, Short circuit and Thermal protection. Operating temperature -40C ~ +60C. Excellent Line and Load regulation. Wide variety of compatible dimmers, flicker free dimming. Dry and Damp Location.
Wattage: 30W, 36W, 60W, 96W, 100W and 150W
Output Voltage: 12VDC and 24VDC Output PWM frequency 20kHz
Input Voltage: Universal 100-277VAC 50/60Hz
All: UL8750 Listed for US and Canada. Class 2 for 12V up to 60W and for 24V up to 96W.
Meet T24, Class P, Type HL, FCC, RoHS, SELV, CE.
Part number Wattage Output Voltage Input Voltage Class 2 Terminal Block Secondary Breaker Num. of circuits
ES60-12UD 		6012VDC 20kHZ PWM100-277V 50/60Hz✔single
ES60-24UD 		6024VDC 20kHZ PWM100-277V 50/60Hz✔single
⇓ click here for more products ⇓
MLE - MINI-LED ELECTRONIC EMCOD MLE Series is Constant Voltage, PWM output, Triac (Phase) Dimmable Electronic LED Driver for Forward and Reverse Phase Dimmers. 5% minimum load. Overload, Short circuit and Thermal protection. Operating temperature -40C ~ +60C. Excellent Line and Load regulation. Wide variety of compatible dimmers, flicker free dimming.
Wattage: 30W, 60W, 80W, 96W, 100W, 120W, 150W, 200W, 300W
Output Voltage: 12VDC and 24VDC
Input Voltage: Universal from 100V to 277V 50/60Hz
All: Black Powder Coated indoor/outdoor enclosure UL, FCC, CE, Class P certified
Part number Wattage Output Voltage Input Voltage Class 2 Terminal Block Secondary Breaker Num. of circuits
MLE60-12DC 6012VDC 450Hz100-277V 50/60Hz✔single
MLE60-24DC 6024VDC 450Hz100-277V 50/60Hz✔single
⇓ click here for more products ⇓
ML - MAG-LED Series is our Revolutionary Compact, dimmable, low profile magnetic LED Drivers on the market. The transformer core and special low drop voltage rectifier are designed to lower losses and make the ML series very efficient , energy saving with low temperature rise. All the ML drivers have primary and secondary self-reset thermal circuit breakers, could be fully loaded, has excelled load regulation, input and output are lead wires.
Wattage: 5W, 10W, 20W, 30W,35W, 40W, 50W, 60W, 75W and 100W
Output Voltage: 12V or 24V, AC or DC
Input Voltage: 120V, 240V, 277V 60Hz and 220V, 230V, 240V 50/60Hz (up to 35W)
All: Outdoor/indoor, Class 2 UL1310 standard, Low profile, Powder coated steel enclosure, Single circuit, Primary and Secondary auto - reset breaker.
Part number Wattage Output Voltage Input Voltage Class 2 Terminal Block Secondary Breaker Num. of circuits
ML60S12AC 6012VAC120V 60Hz✔✔single
ML60S12AC b 6012VAC120V 60Hz✔✔single
ML60S12DC 6012VDC120V 60Hz✔✔single
ML60S12DC b 6012VDC120V 60Hz✔✔single
ML60S12AC277 6012VAC277V 60Hz✔✔single
ML60S12DC277 6012VDC277V 60Hz✔✔single
ML60S12DC277b 6012VDC277V 60Hz✔✔single
ML60S24AC 6024VAC120V 60Hz✔✔single
ML60S24AC-b 6024VAC120V 60Hz✔✔single
ML60S24DC 6024VDC120V 60Hz✔✔single
ML60S24DC b 		6024VDC120V 60Hz✔✔single
ML60S24DC277 6024VDC277V 60Hz✔✔single
ML60S24DC277-b 6024VDC277V 60Hz✔✔single
⇓ click here for more products ⇓
